Operating Instructions for Solar Charge Regulator LRM 1218
7
Date: 22.07.2015
822.0213 BA / EN
For example, five solar modules each rated at 55 Wp can be connected in
parallel:
Per solar module e.g. U
offload
=22V,U
MPP
= 17.2 V
I
MPP
=3.2A
Total nominal current I
MPP
=16A
Battery type
set
Charging-
voltage
Charge reten-
tion voltage
At reference
temperature
Time
phase
Supply mode Fixed voltage 13.4 V
AGM2 14.7 V 13.7 V 25 C 4h
Lead-gel/
AGM1
14.4 V 13.8 V 25 C 12 h
Lead-acid 14.4 V 13.4 V 25 C 4h
The temperature correction of end-of-charge voltages is --20 mV per degree
of temperature increase (in relation to 25 C) or +20 mV per degree of tem-
perature reduction (voltage limits: U
min
13.4 V; U
max
14.9 V; the top voltage
limit at 14.9 V is in consideration of the maximum input voltage of the consu-
mers connected).
F Schaudt electroblocks with SDTBUS (they have a separate input for
the solar currents of leisure and starter batteries, and a connector for
the SDTBUS)
F Schaudt electroblocks with a separate connector for the solar currents
of leisure and starter batteries; possibly also a connection for current
display (relayed to the DT .../LT ... control panel connected to the EBL
...)
F Schaudt electroblocks with a retrofit adapter for charging the starter
battery
F Direct connection to leisure and starter batteries for external systems;
solar current display by LT 320 (available optionally) possible
5.3 Environmental parameters
-10 Cto+50C
-20 Cto+70C
Operation in dry environment only
CE marked
6 Maintenance
The device requires no maintenance.
Clean the device with a soft, slightly damp cloth and mild detergent. Never
use spirit, thinners or similar substances. Do not allow liquids to enter the
device.
No part of this manual may be reproduced, translated or copied without ex-
press written permission.
Calculation example
End-of-charge-
voltages
Suitable EBL ...
electroblocks and other
connection options
Operating temperature
Storage temperature
Humidity
CE
Cleaning
E
