Schaudt LRM 1218 User Manual

Operating Instructions for Solar Charge Regulator LRM 1218
9
Date: 22.07.2015
822.0213 BA / EN
D Customer service
Schaudt GmbH, Elektrotechnik & Apparatebau
Planckstraße 8
88677 Markdorf, Germany
Phone: +49 7544 9577-16 Email: kundendienst@schaudt-gmbh.de
Office hours Mon to Thurs 08.00 -- 12.00, 13.00 -- 16.00
Fri 08.00 -- 12.00
Returning a faulty device:
" Complete and enclose the fault report, see Appendix C.
" Send it to the addressee (free delivery).
E Mechanical layout
1
3
7.5
130.7
90
119
60
ø4 (2x)
135
48
2
345
Fig. 2 Dimensions and connectors for the LRM 1218 solar charge regulator
1 Solar module connection
2 Leisure and starter battery connections, via electroblock as required
3 STDBUS connector
4 Control panel connector, via electroblock as required
5 Battery temperature sensor connector
Customer service
address
Send in device
