Scheer MH 10 Micro - Room Thermostat (Optional)

www.scheer-heizsysteme.de
MH-SERIES
Room thermostat - WLAN (optional)
Please read these operating instructions for all information on the
installation and operation of your thermostat. Ensure that the
thermostat is installed and connected by a professionally qualied
person and that it complies with all regional regulations.
In the box you will nd:
1x Thermostat
1x QC Passed
2x Screws
1x external Floor Sensor (2.5m)
About the thermostat
The thermostat has been developed to control industrial, commercial,, civil or domestic hot water heating sys-
tems, such as radiatiors or underoor heating.
functions
• N etworking through Modbus and WLAN
• 0.5 ° C given
• Short-term memory in the event of a power failure
• 5 + 1 + 1 weekly program with 6 periods comprehensive time program
• Controllable by Amazon Echo, Google Home, Tmall Genie
dimensions
86
86
39
2613
26
26
Room thermostat Item No.
incl. WLAN connection 0170106
Technical Data
Power Supply 95~240VAC, 50~60Hz Timing error <1%
Current Load max 5A Shell Material PC + ABS (re proof)
Sensor NTC3950, 10k Installation Box
86x86mm square/
Europ. 60mm round
Accuracy ±0,5°C Wire Terminals 2*1,5mm² / 1x2,5mm²
Set Temp. Range: 5-35°C Protection Class IP20
Display Temp. Range 5~99°C Storage Temp -5~45°C
Ambient Temp.: 0~45°C Power Consumption <1,5W
Ambient Humidity: 5~95% RH (not condensing)
10
