Scheiber BATTERY VIEWER User Manual

17
TECHNICAL CHARACTERISTICS
TECHNICAL CHARACTERISTICS
PART NUMBER
43.00002.00 (12V) or 43.00004.00 (24V)
THIS KIT INCLUDES
1 tactile color screen Navicolor 3.5’
1 IBS sensor (Intelligent Battery System) 12V or 24V
1 cable for IBS sensor
1 cable for the connection between the sensor and the panel
2 battery terminals
COMPATIBLE BATTERIES
GEL, LEAD (liquid), AGM
PANEL SIZE (L x l x P)
150 x 95 x 65 mm (with cable connected)
WEIGHT
0,850 Kg
IBS TECHNICAL CHARACTERISTICS
INFORMATION
IBS 12V
IBS 24V
Measuring range
± 1200 A
± 1200 A
Maximum current
± 1500 A
± 1600 A
Permanent current
± 155 A
± 200 A
Maximum battery capacity
249 Ah
249 Ah
BATTERY VIEWER DISPLAY
Voltage (V)
Batterie’s voltage (or battery park)
Current (A)
Loading current (« + » value and arrow up)
Discharge current (« - » value and arrow down)
Nominal capacity (Ah)
Battery capacity under 20 hours (discharge curve C/20)
Value to configure
See SYSTEM AND IBS SETTINGS
Available capacity (Ah)
Available battery capacity according to the state of health (SoH)
Discharge capacity (Ah)
Discharge battery capacity de la batterie calculated in accordance with the state of
charge (SoC)
State of charge (%)
Battery state of load calculated from algorithms integrating the following
information: voltage/current/temperature
Health state (%)
Ageing of the battery
Temperature (°C)
Temperature the battery where the IBS sensor is connected
IBSx
Symbolizes a 12VDC IBS sensor (automatic detection)
IBSx
Symbolizes a 24VDC IBS sensor (automatic detection)
Symbolizes a 12VDC battery park
Symbolizes a 24VDC battery park
