P. 3
L’innovation française depuis 1965
BLOC 11
REFERENCE 41.70521.00 XXX XXX
POWER SUPPLY 8-32 V DC
DETAILS AND FEATURES OF THE INPUTS 6 plus digital inputs
DETAILS AND FEATURES OF THE OUTPUTS 6 relay outputs 1A potential free (32V max.)
CAN BUS 2 x connectors type 6-way Micro-Fit
ENVIRONMENTAL CONDITIONS
Indoor use
Altitude up to 2000m
Operating temperature: 0 to +50 °C
Relative humidity: 0 to 93% - non-condensing
Protection index: IP20
MOUNTING 4 screws
MOUNTING DISTANCE 100 x 59 mm
WEIGHT 0,19 Kg
STANDARDS EN 60945
FIRMWARE VERSION V8.00 or higher
DIMENSIONS
(
LxWxH
)
160 x 95 x 50 mm
INPUT RATED VOLTAGE
(
VDC
)
8-32 VDC
SELF
-
CONSUMPTION 45 mA
MAXIMUM CURRENT PER OUTPUT 1A
MAXIMUM CUMULATIVE CURRENT 5A
Electrical characteristics
Description of the markings used
V Volt
A Ampere
ou DC Direct current
Technical characteristics
