1716
GB
TECHNICAL DATA
Power supply unit operating voltage 230 V / 50 Hz
Rated power 70 W
Standby power 1 W
Torque 8 Nm
Max. speed 36 rpm
Max. tensile force / initial tensile
force
30 kg
Short-time operation 4 minutes
Enclosure rating IP 20 (for dry rooms only)
Protection class II
Automatic solar control setting range 2.000 bis 20.000 Lux
Dimensions see page 200
Permissible belt widths 23 mm (maxi belt) and
14 mm (mini-belt)
Belt length Maxi: 4,0 m bei 1,3 mm Gurtstärke
5,0 m bei 1,0 mm Gurtstärke
Mini: 4,0 m bei 1,3 mm Gurtstärke
Max. shutter surface area 5,0 m² plastic
2,5 m² aluminium
Notes:
The specications provided are recommended values and apply to ideal installa-
tion situations. Due to existing site conditions, the values may be dierent.
Only use the product with roller shutter belts with the dimensions indicated in the
„Technical data“ table� Wrong shutter belt lengths and widths will result in dama-
ge� Replace the old shutter belt when the requirements are not met�
Caution: regularly check the paneling as well as the belt for their awless con-
dition� In case of risk, decommission the system and have repairs executed by a
specialist�
Note: since the belt pulley in the roller shutter box loses its rigidity due to aging, we
recommend checking and if necessary replacing it after a prolonged usage time�
If the maximum motor run time is exceeded by 4 minutes, the LED clock will ash
quickly and the motor will stop� After approx� 60 minutes, the motor will have its
full operational readiness again�
