follow its information. The machine can only
be operated by persons who were instruct-
ed concerning the operation of the machine
and who are informed about the associat-
ed dangers. The minimum age requirement
must be complied with.
In addition to the safety notices contained
in this operating manual and the particular
instructions for your country, the general-
ly recognised technical regulations for the
operation of identical devices must be com-
plied with.
2. Layout
Fig. 1 (1 - 20)
1. Handle
2. Drive lever
3. Engine brake lever
4. Upper push bar, 4a lower push bar
5. Quick-release lever
6. Petrol tank
7. Air lter
8. Side discharge
9. Wheel
10. Spark plug
11. Exhaust
12. Dip stick
13. Drive wheel
14. Wheel height adjustment
15. Discharge ap
16. Grass box
17. Pull starter
18. Cable clips
19. Mulch insert
20. Primer button
3. Scope of delivery
Fig. 1 (a - e)
a) 2 x round head screw M8
b) 2 x washer big
c) 4 x washer small
d) 4 x plastic star grip nut
e) 1 x manual
1. Introduction
MANUFACTURER:
scheppach
Fabrikation von Holzbearbeitungsmaschin-
en GmbH
Günzburger Straße 69
D-89335 Ichenhausen
DEAR CUSTOMER,
We hope your new tool brings you much en-
joyment and success.
NOTE:
According to the applicable product liability
laws, the manufacturer of the device does
not assume liability for damages to the
product or damages caused by the product
that occurs due to:
• Improper handling,
• Non-compliance of the operating instruc-
tions,
• Repairs by third parties, not by authorized
service technicians,
• Installation and replacement of non-orig-
inal spare parts,
• Application other than specied,
• A breakdown of the electrical system that
occurs due to the non-compliance of the
electric regulations and VDE regulations
0100, DIN 57113 / VDE0113.
WE RECOMMEND:
Read through the complete text in the op-
erating instructions before installing and
commissioning the device. The operating
instructions are intended to help the user to
become familiar with the machine and take
advantage of its application possibilities in
accordance with the recommendations. The
operating instructions contain important in-
formation on how to operate the machine
safely, professionally and economically,
how to avoid danger, costly repairs, reduce
downtimes and how to increase reliability
and service life of the machine.
In addition to the safety regulations in the
operating instructions, you have to meet the
applicable regulations that apply for the op-
eration of the machine in your country. Keep
the operating instructions package with the
machine at all times and store it in a plas-
tic cover to protect it from dirt and moisture.
Read the instruction manual each time be-
fore operating the machine and carefully
