In addition to the safety instructions in this operating
manual and the separate regulations of your country,
the generally recognised technical rules relating to the
operation of such products must also be observed.
We accept no liability for accidents or damage that
occur due to a failure to observe this manual and the
safety instructions.
2. Product description (g. 1)
1. Return hose
2. Extraction hose
3. Pressure regulator
4. Storage compartment for nozzles and HEA lters
5. Nozzle
6. Retainer
7. Paint spray gun
8. Handle
9. Trigger lever
10. Connection thread
11. HEA lter
12. High-pressure hose
13. Function switch
14. Connection thread
15. Suction lter
16. Valve pushers
17. Filter plate
18. Plastic ring
19. Holder
20. Nozzle chamber
21. Nozzle holder
22. Spring
23. Washer
24. Ball
25. O-ring
26. Inlet valve
27. Fixing screw
28. Allen screw
29. Hose clamps
3. Scope of delivery
Item Quantity Designation
1x Paint spray system (main unit)
12 1x High-pressure hose
7 1x Paint spray gun
11 1x HEA lter (1x pre-assembled)
5 2x Nozzle (311/517)
1. Introduction
Manufacturer:
Scheppach GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Dear Customer,
We hope your new product brings you much enjoyment
and success.
Note:
In accordance with the applicable product liability laws,
the manufacturer of this product assumes no liability
for damage to the product or caused by the product
arising from:
• Improper handling
• Non-compliance with the operating manual
• Repairs carried out by third parties, unauthorised
specialists
• Installing and replacing non-original spare parts
• Application other than specied
• Failure of the electrical system in the event of the
electrical regulations and VDE provisions 0100,
DIN 57113 / VDE0113 not being observed
Note:
Read through the complete text in the operating manu-
al before installing and commissioning the device.
This operating manual should help you to familiarise
yourself with your product and to use it for its intended
purpose.
The operating manual includes important instruc-
tions for the safe, proper and economic operation of
the product, for avoiding danger, for minimising repair
costs and downtimes and for increasing the reliability
and extending the service life of the product.
In addition to the safety instructions in this operating
manual, you must also observe the regulations appli-
cable to the operation of the product in your country.
Keep the operating manual package with the power
tool at all times and store it in a plastic cover to pro-
tect it from dirt and moisture. They must be read and
carefully observed by all operating personnel before
starting the work.
The product may only be used by personnel who have
been trained to use it and who have been instructed
with respect to the associated hazards.
The required minimum age must be observed.
