ww w.scheppach.com
34
|
GB
Filling hole for chain oil.
CHOKE
pressed - Choke disabled
pulled out - Choke activated
10x
Primer button for cold start
Adjustments for carburettor:
L Low Speed
H High Speed
T Idle Speed
Setting the chain tension:
White arrow: Loosen chain
Black arrow: Tighten chain
Installation direction of chain
Guaranteed sound power level of the device.
Attention! Hot surface
ON
ON-/OFF switch - “ON”
ON-/OFF switch - “STOP”
Weight
Mixing ratio
Avoid contact with the tip of the bar
Fire prohibited
