14
DP5000
Engine 196 cc, 6,5 HP
Transmission 3F+1R
Load Capacity 500 kg
Box Length 950mm
Box width 680 mm
Box Depth 465 mm
Track Width
180mm
Sound power
level (LwA )
meas./guar.
100,7 / 103 dB(A) k=3 dB(A)
Sound pressure
level(LwA)
91,8 dB(A) k=3 dB(A)
Vibrating level on
handlebar grips:
(m/s2)
Left 10.1 m/s
2
k=1.5 m /s
2
Right 11.3 m/s
2
k=1.5 m /s
2
Pump Flow 9.0 L/min
Weight 255.5 kg
Drive:
Engine Type 4-stroke engine
Capacity 196 ccm³
Idle 3000 1/min.
Maximum Speed 3600 1/min.
Motor Starters Recoil starter (pull starter)
Power 4,8 kW
Fuel
Unleaded gasoline octane
number from 90 to a maximum
ethanol content of 5%
Maximum fuel
tank capacity
3,6 l
Required motor
oil
SAE 10W-30
Oil tank capacity
maximum
0,6 l
Subject to techcnical modications!
Environmental
Recycle unwanted materials instead of disposing of
them as waste. All tools, hoses and packaging should
be resorted, taken to the local recycling center and dis-
posed of in an environment-friendly safe way.
Symbols
Wear eye protection.
Wear hearing protection.
Read these instructions for use
carefully.
Wear safety footwear.
Wear safety gloves.
NOTE:
According to the applicable product liability law the man-
ufacturer of this device is not liable for damages which
arise on or in connection with this device in case of:
• improper handling,
• non-compliance with the instructions for use,
• repairs by third party, non authorized skilled workers,
• installation and replacement of non-original spare
parts,
• improper use,
• failures of the electrical system due to the non-com-
pliance with the electrical specications and the
VDE 0100, DIN 57113 / VDE 0113 regulations
RECOMMENDATIONS:
Read the entire text of the operating instructions prior to
the assembly and operation of the device.
These operating instructions are intended to make it
easier for you to get familiar with your device and utilize
its intended possibilities of use.
The operating instructions contain important notes on
how to work safely, properly and economically with your
machine and how to avoid dangers, save repair costs,
reduce downtime, and increase the reliability and work-
ing life of the machine.
In addition to the safety regulations contained herein,
you must in any case comply with the applicable regula-
tions of your country with respect to the operation of the
machine.
Put the operating instructions in a clear plastic folder to
protect them from dirt and humidity, and store them near
the machine. The instructions must be read and care-
fully observed by each operator prior to starting the work.
Only persons who have been trained in the use of the
machine and have been informed on the related dangers
and risks are allowed to use the machine. The required
minimum age must be met.
In addition to the safety notes contained in the present
operating instructions and the special regulations of your
country, the generally recognized technical rules for the
operation of wood working machines must be observed.
