www.scheppach.com
26
|
GB
Technical changes reserved!
* The duty cycle S2 20 min (short-time duty)
states that the motor may only be continu-
ously loaded with the rated power (1200 W) for
the time specied on the data plate (20 min).
Otherwise, it would heat up impermissibly.
During the pause, the motor cools down again to
its initial temperature.
Noise & vibration
m Warning: Noise can have serious eects on your
health. If the machine noise exceeds 85 dB (A), please
wear suitable hearing protection.
Noise data
Sound power level L
WA
116 db(A)
Sound pressure level L
pA
: 95 db(A)
Uncertainty K
wa/pA
3 db
7. Unpacking
• Open the packaging and carefully remove the prod-
uct.
• Remove the packaging material, as well as the pack-
aging and transport safety devices (if present).
• Check whether the scope of delivery is complete.
• Check the product and accessory parts for transport
damage. In the event of complaints the carrier must
be informed immediately. Later claims will not be
recognised.
• If possible, keep the packaging until the expiry of the
warranty period.
• Familiarise yourself with the product by means of the
operating manual before using for the rst time.
• With accessories as well as wearing parts and re-
placement parts use only original parts. Replace-
ment parts can be obtained from your dealer.
• When ordering please provide our article number as
well as type and year of manufacture for your prod-
uct.
m WARNING!
The device and the packaging material are not
children’s toys! Do not let children play with plas-
tic bags, lms or small parts! There is a danger of
choking or suocating!
• Cooling of the cutting wheel: Make sure that the
cutting wheel is cooled with water during the entire
cutting process.
• Always ll the pan with water before working.
Residual risks
The machine has been built according to the state-of-
the-art and the recognised technical safety require-
ments. However, individual residual risks can arise
during operation.
• Health hazard due to electrical power, with the use
of improper electrical connection cables.
• Before performing setting or maintenance work, re-
lease the start button and pull out the power plug.
• Furthermore, despite all precautions having been
met, some non-obvious residual risks may still re-
main.
• Residual risks can be minimised if the “Safety infor-
mation” and the “Proper use” together with the oper-
ating manual as a whole are observed.
• Avoid accidental start-ups of the machine: The oper-
ating button may not be pressed when inserting the
plug in a socket. Use the tool that is recommended
in this operating manual. This is how to ensure that
your machine provides optimum performance.
• Keep your hands away from the work area, when the
machine is in operation.
6. Technical data
FS4700 FS3600
Motor power 1200 W 900 W
Operating mode S2 20 min*
Motor speed 3000 rpm
AC motor 230 V~ 50 Hz
Insulation material class F
Protection category IP54
Cut length 1200 mm 920 mm
Cutting height 90° 40 mm 36 mm
Cutting height 45° 34 mm 29 mm
Cutting table
Dimensions
400 x
1377 mm
400 x
1290 mm
Working height 780 mm
Diamond cutting wheel
Ø 230
mm x Ø
25.4 mm
Ø 200
mm x Ø
25.4 mm
Weight 57 kg 51.5 kg
