Explanation of the symbols on the device
Read the operating and safety instructions before start-up and follow them!
Place the concrete mixer horizontally on level and rm oor!
Concrete mixer must not be moved during operation!
Keep unauthorised persons and children away from the device!
The device has protective insulation!
Attention! The protection class is only maintained if original insulating materials
are used during servicing and the insulation distances are not changed.
Pull out the mains plug before cleaning or maintenance!
Size: 20 (mm) 40 (mm)
Ø 25 mm
129 x 70
Concrete mixer may only be operated with the guard fully closed!
Wear protective clothing!
Do not reach into the drum when it is moving!
Caution!
Danger of crushing on the sprocket
Assembly support!
See: Assembly, Fitting the drum upper section (g. 6)
