Explanation of the symbols on the device
Symbols are used in this manual to draw your attention to potential hazards. The safety symbols and the accompa-
nying explanations must be fully understood. The warnings themselves will not rectify a hazard and cannot replace
proper accident prevention measures.
Caution - Read the operating instructions to reduce the risk of inquiry.
EN 60974-1
European standard for welding sets for manual arc welding with limited on time.
1~
f
1
f
2
Single-phase static frequency converter transformer rectifier
Direct current
Power input; phase number, as well as
Alternating current symbol and rated value of the frequency
U
0
Rated idling voltage
U
1
Mains voltage
l
2
Cutting current
U
2
Operating voltage [V]
l
max
Rated maximum mains current
l
e󰀨
Effective value of the highest line current [A]
IP21S
Protection type
H
Insulation class
Caution! Risk of electric shock!
Electric shock from the welding electrode can be fatal.
Inhaling welding smoke can be hazardous to your health.
Electromagnetic fields can interfere with the functionality of pacemakers.
Welding sparks can cause an explosion or fire.
Arc rays can damage the eyes and injure the skin.
Do not use the device outdoors and never in rain!
Cutting with the plasma cutter.
Connection – Ground terminal plug
Connection – plasma burner - Power plug
Connection – plasma burner
m Attention!
In this operating manual, we have used this sign to mark all sections that concern
your safety.

Scheppach PLC40 Specifications

General

Control type	Rotary
Easy to read	Yes
Product color	Black
Built-in display	No
Cutting thickness (max)	12 mm
Input current	40 A

Weight and Dimensions

Depth	430 mm
Width	280 mm
Height	310 mm
Weight	8650 g
