Rated voltage
max. 20 V
Capacity 2.0 Ah
Power 40 Wh
Max. temperature. 50°C
Charging process temperature 4 °C – 40 °C
Operation temperature -20 °C – 50 °C
Storage temperature 0 °C – 45 °C
Subject to technical changes!
7 Before commissioning
7.1 Wall mounting - Charger
WARNING
– Before wall mounting, make sure that there are no lines in the wall in the area of the drill holes
that could be damaged.
– Lay the mains cable so that it does not obstruct you and no one can accidentally pull on it.
– Children must not play with the product, even if it is hanging on the wall.
– Mounting behind doors and their swinging range is not recommended, as there is a risk of
tearing off or otherwise damaging the product.
WARNING
The product must never be operated on a combustible surface.
WARNING
Never attach the product to a wet surface.
* = not included in the scope of delivery!
The battery charger has two holes on its back for wall mounting with two screws*. It can be hung on a
wall, taking into account the safety instructions and the dimensions given (see Fig. 3).
8 Operation
8.1 Charge battery
Charge the battery at an ambient temperature of 4 °C to 40°C.
1. Push the battery (4) into the battery mount (1) up to the stop.
2. Plug the mains plug into the socket. The LED strip (3) lights up green.
3. As soon as the charging process starts, the LED strip (3) flashes green.
4. The LED strip (3) lights up green when charging is complete. The battery (4) is ready for use.
GB | 21www.scheppach.com
