Operating Instructions for Actuators Type AB with Control Unit
OM-ENGLISH-ABCSC.V1.2-16xx-V2.02-2023.04.27
SEC-OM-ENGLISH-ABCSC-V1.2-16xx-V2.02-2023.04.27
Operating Instructions for Actuators Type AB with Control Unit
1 Introduction/Notes
NOTE: These operating instructions apply to SCHIEBEL actuators of the type AB with integrated ACTUSMART
control unit version V1.2 with a firmware version of 1600 or newer.
The scope of application covers the operation of industrial valves, e.g., globe valves, gate valves, butterfly
valves and ball valves. For other applications please consult with the factory.
The manufacturer shall not be liable for incorrect use and possible damage arising thereof. The risk shall be
borne solely by the user.
NOTE: Using the unit as intended also entails the observance of these operating instructions!
WARNING: When operating electrical equipment, certain
parts inevitably carry hazardous voltage levels. Work on
the electrical system or equipment must be carried out
only in accordance with electrical regulations by a qualified
electrician himself or by specially instructed personnel under
the control and supervision of a qualified electrician.
CAUTION: Maintenance instructions must be observed as other-
wise the safe operation of the actuator cannot be guaranteed.
WARNING: Failure to follow the warning information may
result in serious bodily injury or property damage. Qualified
personnel must be thoroughly familiar with all warnings
contained in this operating manual.
CAUTION: Proper transport, storage, installation, assembly and
careful commissioning are essential to proper and safe operation.
WARNING: When working in potentially explosive areas,
observe the European Standards EN 60079-14 ”Electrical
Installations in Hazardous Areas” and EN 60079-17 ”Inspec-
tion and Maintenance of Electrical Installations in Hazardous
Areas”.
WARNING: Maintenance work on open actuators may only be
conducted if these are de-energized. Reconnection during
maintenance is strictly prohibited.
