Service Manual L
101
Armor Fronts
* For use with 1
³⁄₈
” thick doors. Use with 1
¹⁄₁₆
” Faceplate Tab L583-427.
Function and
Description
Function and
Description
1¹⁄₄''
Square Corner
1¹⁄₁₆''
Square Corner*
1¹⁄₄''
Square Corner
1¹⁄₁₆''
Square Corner*
Blank Deadbolt
09-661 09-667
L9110
L9175
L9176
09-665 09-671
L9460
L9462
L9463
L9464
Latch Latch x Aux Latch x Deadbolt
09-662 09-668
UL
L9010
L9040
LV9040
L9044
LV9044
09-666 09-672
UL
L9453
LV9453
L9480
LV9480
L9482
LV9482
L9485
LV9485
L9486
LV9486
Latch x Auxiliary Latch Latch x Aux Latch (holdback)
09-663 09-669
UL
L9050
LV9050
L9056
LV9056
L9060
LV9060
L9070
LV9070
L9071
LV9071
L9080
L9082
LV9082
09-713
L9076
LV9076
L9077
LV9077
Latch x Deadbolt Deadbolt
09-664 09-670
UL
L9440
LV9440
L9444
LV9444
L9456
LV9456
L9457
LV9457
L9465
L9466
L9473
L9496
LV9496
09-717
L460
L462
L463
L464
L480
L496
