MAINTENANCE
46 | EN www.schmalz.com 30.30.01.00174/06
Interval
Daily
Weekly
Monthly
Every
six
months
Annual
check
Are all connections (hose clamps, etc.) secure?
X
Are the type plate and maximum load plate still
attached to the device?
X
Are the operating instructions still present and
are workers familiar with them?
X
Is the latching bolt secure?
X
Check all load-bearing parts (e.g. suspension of the
Jumbo) for deformation, wear, rust or other damage.
X
X
Check whether the filter is soiled
X
X
Grippers
Is the seal of the tube holder/gripper OK?
X
X
Does the suction pad still fit tightly; is it working
properly?
Are the sealing lips even? Replace as needed
X
X
Is the filter fleece in the suction pad clean?
X
X
Function
Can the device be easily raised and lowered when
not carrying a vacuum-gripped load?
X
X
Can the hovering position be set easily when the
device is carrying a load? (by turning the adjusting
screw on the operator handle)
X
Does the non-return valve work when there is a
power failure?
X
X
X
Is the UVV (German Accident Prevention
Regulations) test label current?
X
General condition of the device
X
9.5 Cleaning
Use cleaning solvents to clean the vacuum tube lifter JUMBO (not petroleum ether or corrosive liquids;
the use of petroleum ether or corrosive liquids could cause leaks in the supply hose or lift tube). The
suction plates can be cleaned using soap and warm water; do not use cleaning solvents on the
suction sealing lips!
9.6 Vacuum pump
Only for versions with electrical vacuum generator:
See enclosed pump operating instructions
9.7 Ejector
Only for versions with pneumatic vacuum generator:
See enclosed pump operating instructions
