SCHUBERTH M1 Quick Start Guide

6 7
3. OPENING AND CLOSING THE CHINSTRAP
To close the chinstrap fastener, slide the ratchet tongue step by step into the
locking buckle. If you nd that the chinstrap ts too loosely around your chin,
slide the ratchet tongue one step further into the locking buckle.
4. ADJUSTING THE CHINSTRAP
The length of the chinstrap is adjusted by increasing or reducing the length of
strap pulled through the metal buckles. Adjust the length of the chinstrap so that
it ts rmly but comfortably under your chin and x the end of the strap using the
retaining loop with comfort pad.
2. HEAD VENTILATION AND SUN VISOR
1. ANATOMY OF THE HELMET
Visor
Sun visor
Loudspeaker
Microphone
Chin strap with
ratchet fastener
Head ventilation
Inner shell
Reective eyes
Head ventilation
Visor mechanism
Outer shell
Inner lining
Restraint system
(with anti-roll-o-
system)
Sun visor control
We recommend that, in addition to carefully reading the Quick Start Guide, you
should also read the instructions for the SRC-System
™
, in order to understand all
the functions and the correct operation.
To nd the complete manual please go to:
www.SCHUBERTH.com
EN

SCHUBERTH M1 Specifications

General

Helmet Type	Open Face
Shell Material	Fiberglass
Visor	Integrated Sun Visor
Standard	ECE 22.05
Communication System	Optional
Ventilation	Adjustable
Interior	Removable and washable
Closure	Micro-lock ratchet
