00-99-000931/0109
Models / Modelos: SE-40MAP, SE-70MA, SE-82-6,
SE-125A, SE-520MA, SE-1010-2, SE-1052, SE-1250,
SE-1275A, SE-1510MA, SE-2151MA, SE-5212A, SF-82-6,
SF-125A, SF-50MA-2, SF-200-30, SF-1010-2, SF-1252MA,
SF-1275A, SF-2151MA Battery Chargers / Cargadores De
Batería / Chargeur de batterie
READ ENTIRE MANUAL BEFORE
USING THIS PRODUCT
LEA EL MANUAL COMPLETO ANTES DE
UTILIZAR ESTE PRODUCTO
LIRE ENTIÈREMENT LE GUIDE AVANT
D’UTILISER CE PRODUIT
OWNER’S MANUAL
MANUAL DEL USUARIO
GUIDE D’UTILISATION

Table of Contents

Questions and Answers

  • S
    Shelby PrinceAug 3, 2025
    What to do if my Schumacher Electric SF-50MA-2 has no reading on the ammeter?
    • R
      Roy SimmonsAug 3, 2025
      If your Schumacher Electric Battery Charger shows no reading on the ammeter, several issues could be the cause. First, ensure the charger is properly plugged into a working AC outlet with no blown fuse or tripped circuit breaker. Check that the clips are making good, clean connections to the battery and frame; rocking them back and forth can help. Also, verify the connections are not reversed. If these steps don't resolve the issue, the battery itself may be defective or the 2 amp charge rate is being used (ammeter may show no activity at the 2A charge rate).
  • B
    Bryan FloresAug 8, 2025
    Why does my Schumacher Electric SF-50MA-2 Battery Charger make a loud buzz or hum?
    • J
      Jonathan WhiteAug 8, 2025
      A buzzing sound from your Schumacher Electric Battery Charger usually indicates that the transformer laminations are vibrating, which is normal. However, a humming sound may indicate a shorted diode assembly or output rectifier assembly, which would require a qualified technician to check the charger.
  • C
    christophercrawfordAug 12, 2025
    What to do if my Schumacher Electric SF-50MA-2 ammeter reading stays high?
    • M
      Michael MitchellAug 12, 2025
      If the ammeter reading on your Schumacher Electric Battery Charger remains high, it could mean that the battery is severely discharged; in that case, continue charging the battery for two more hours. It could also indicate the wrong battery voltage. If the problem continues, have the battery checked and verify the voltage settings on the charger are correct.
  • W
    whitepattyAug 16, 2025
    How to troubleshoot a Schumacher Electric SF-50MA-2 that won't turn on?
    • E
      Erin WagnerAug 16, 2025
      If your Schumacher Electric Battery Charger doesn't turn on when properly connected, first check that the AC outlet is functional by testing it with another device or checking the fuse or circuit breaker. Also, inspect the power cord and any extension cords for loose connections.
  • M
    Mr. Douglas Taylor DDSAug 21, 2025
    Why does my Schumacher Electric SF-50MA-2 make a clicking sound?
    • N
      Nancy Irwin DDSAug 21, 2025
      A clicking sound from your Schumacher Electric Battery Charger can be caused by several factors. The circuit breaker might be cycling, indicating incorrect settings, so check the charger settings. The battery could be defective, or there might be shorted battery cables or clips. A severely discharged battery might also cause this, in which case, allow charging to continue. Finally, reverse connections at the battery can cause a clicking sound, so shut the charger off and correct the lead connections.
  • M
    Mark WalkerAug 25, 2025
    What causes short start cycles with my Schumacher Electric SF-50MA-2 Battery Charger?
    • R
      Robert RobinsonAug 26, 2025
      Short or no start cycles when cranking the engine using your Schumacher Electric Battery Charger can occur for several reasons. You might be drawing more than the engine start rate, as crank time varies with current draw. Ensure you wait 3 minutes between cranks to allow the battery and charger to cool down. Check for poor connections at the battery and frame, and ensure the AC cord and any extension cords are securely plugged in. Verify that the outlet has power. The charger may be overheated, or the battery may be severely discharged; in the latter case, charge for 10 to 15 minutes in the highest manual rate to assist in cranking.
  • A
    Alejandro DavidsonAug 29, 2025
    What to do if the ammeter reads less than selected charge rate on my Schumacher Electric SF-50MA-2?
    • B
      Brandy ClarkAug 29, 2025
      If the ammeter on your Schumacher Electric Battery Charger reads less than the selected charge rate when charging a discharged battery, the extension cord may be too long or the wire gauge too small; try using a shorter or heavier gauge cord. It could also indicate a weak cell or sulfated plate in the battery; a sulfated battery will eventually take a normal charge if left connected. Finally, the battery may only be partially discharged, so continue to charge the battery.

Summary

Important Safety Instructions

General Safety and Warning Guidelines

Comprehensive safety guidelines including warnings about chemicals, sparks, and explosive gases.

Personal Precautions

Safety Measures and Battery Rules

Precautions for personal safety, battery handling, and charging rules.

Preparing to Charge

Battery Preparation

Steps for preparing the battery, including removal, ventilation, cleaning, and adding water.

Pre-Charge Checks and Settings

Read instructions, verify voltage, and ensure secure cable connections before charging.

Charger Location

Placement Guidelines

Guidelines for locating the charger away from the battery in a well-ventilated area.

DC Connection Precautions

Safe DC Connection Procedure

Procedures for safely connecting and disconnecting DC output clips.

Follow These Steps When Battery is Installed in Vehicle

Vehicle Connection Safety

Safety measures and cable routing for connecting charger to a vehicle battery.

Polarity, Grounding, and Connection

Checks for polarity, grounding, and steps for connecting clips based on vehicle ground.

Vehicle Disconnection Procedure

Proper procedure for disconnecting the charger from the vehicle battery.

Battery Charging - AC Connections

AC Connection Requirements

Charger requires a 120V circuit with a properly installed grounded outlet.

Extension Cord Guidelines

Table provides recommended AWG wire sizes for extension cords based on charger input.

Control Panel

Model Specific Features

Control panels vary by model; not all switches and LEDs are available on all units.

Ammeter Explanation

Understanding the Ammeter

Explains the ammeter's function in indicating current draw and its behavior during charging.

Operating Instructions

Understanding Charge Indicators

Explains Percent of Charge scale, Battery Type Switch, and Charge Rate Selector.

Charging Modes and Indicators

Details Automatic Charging, Manual Charging, Completion of Charge, and LED indicators.

Using Engine Start Feature

Instructions for using the engine start feature safely and effectively.

Calculating Charge Time

Charge Time Estimation Table

Table to determine charging time based on battery size and charger rate.

Maintenance Instructions

Cleaning and Care

Instructions for cleaning the charger and its components after use.

Storage Instructions

Proper Storage Guidelines

Guidelines for storing the charger unplugged in a cool, dry place.

Troubleshooting

Ammeters and Charging Issues

Troubleshooting common problems related to the ammeter and charging.

Charger Operation Problems

Solutions for issues like no reading, high reading, clicking sounds, or buzzing.

Engine Start Issues

Troubleshooting problems related to the engine start function.

Before Returning for Repairs

Troubleshooting and Contact

Steps to take before returning for repairs, including checking connections and contacting support.

Limited Warranty

Warranty Terms and Conditions

Details the two-year limited warranty, exclusions, and limitations.

Schumacher Electric SF-50MA-2 Specifications

General IconGeneral
Input Voltage120V AC
Output Voltage6V/12V
Output Current50A
TypeAutomatic
Battery TypeAGM, Gel
Cable Length36 inches
