Technical data
2-channel nerve and muscle stimulator with electrically insulated channels, 12 integrated
constant current characteristic programs and from series C 3 user programs for own
settings.
Power supply: 6.0 V (4 x 1.5 V battery AAA type micro e. g. LR03)
or 4.8 V (4 x 1.2 V rechargeable battery AAA)
Output current: Max. 100 mA (therapy) approx. 60 µA (power down)
Dimensions: Approx. 140 mm x 64 mm x 28 mm
Weight: Approx. 96 g (without batteries)
Output current: 0 - 60 mA (with 1 kΩ load)
Pulse form: biphasic rectangle
Frequency range: 1-120 Hz
Pulse width: 75-300 µs
Operating conditions: Temperature range: 10 °C to 40 °C
Relative humidity: 30 % to 90 %
Storage conditions: Temperature range: -10 °C to 55 °C
Relative humidity: 10 % to 90 %
Pulse forms
with 1kΩ load (P1-P16)
Output Power,
Voltage
Time
with ANSI/AAMI standard load (P1-P15)
Voltage
Time
Output Power
Time
