20
3. Remove the bushings and hardware from the Seat Rail Assembly. Set
them safely aside. Slide the Seat off the Seat Rail Assembly.
NOTICE: Do not crimp the cables.
4. Installation is the reverse procedure.
NOTICE: Do not crimp the cables. When you reinstall the seat, make
sure that the Schwinn
™
name on the seat points away from
the Rower Engine, so that the RPM Sensor Magnet is on the
correct side of the Seat Rail.
5. Inspect your machine to ensure that all hardware is tight and
components are properly assembled.
Do not use until the machine has been fully assembled and
inspected for correct performance in accordance with the
Owner’s Manual.
6mm
5mm
