DB14
Scientech Technologies Pvt. Ltd. 4
Introduction
DB15 is a compact, ready to use BCD to 7 Segment Decoder experiment board. This
experiment board has been designed to study BCD to 7 Segment decoder using
IC74LS47. The Experiment board has inbuilt common anode display to study
functionality of 74LS47. It can be used as stand alone unit with external Power
Supply or can be used with Scientech Digital Lab ST2611 which has built in Power
Supply, pulse generator, pulser switches, 8 bits data switches, logic probe, digital
display, 8 bits LED display.
List of boards :
Model Name
DB01 Logic Gates
DB02 Universal Gate- NAND/NOR
DB03 EX-OR Gate Implementation
DB04 Demorgan's Theorem
DB05 EX-OR Gate Application
DB06 Code Conversion (Binary to Gray & Gray to Binary)
DB07 Code Conversion (BCD to Excess-3 code)
DB08 Binary Adder -Subtractor
DB09 Encoder – Decoder
DB10 Multiplexer – Demultiplexer
DB11 Flip-Flops (R-S, D, J-K, T)
DB12 Shift Register (4 bit SIPO)
DB13 4 Bit Synchronous Binary Counter
DB16 Digital to Analog Converter (R-2R ladder)
DB17 3 Digit Event Counter
DB21 Fiber Optic Digital Link
DB22 Analog to digital converter (Counter Type)
DB27 Digital to Analog Converter (R-2R ladder)
DB28 Monostable Multivibrator
DB29 CMOS and Crystal Oscillator
DB30 Adder/ Subtracter (4-Bit/8-Bit)
DB31 Decoder/Demultiplexer
DB32 Modulo-N programmable counter
DB35 4 BIT Shift Register
………and many more
To Next Page
