PRODUCT DESCRIPTION
THESE INSTRUCTIONS MUST BE FOLLOWED FOR US TO
GUARANTEE OUR FULL SUPPORT OF YOUR CLAIM FOR
PROTECTING AGAINST LOSS FROM CONCEALED DAMAGE.
THE FORM FOR FILING SUCH A CLAIM WILL BE PROVIDED
BY THE CARRIER.
UNPACKING
Unpack the product and check for any damage incurred during
transit. This should be reported to the responsible carrier, railway or
postal authority, and a request for a damage report should be made.
GENERAL INSTALLATION AND OPERATION INFORMATION
• Install the unit in the most convenient location for ease of clean-
ing, maintenance and general operation.
• Ensure that the surface is level.
• If the appliance is to be positioned in close proximity to a wall,
partition, etc, it is recommended that they are of non-combusti-
ble heat insulating material, and the closest attention paid to re
prevention regulations.
• The units are provided with a simple device for automatic control
of water level.
• The manual reset safety thermostat protects the element should
the bath run dry.
Part
No.
1 RING KNOB
2 CENTRE RING
3 65MM RING
4 85MM RING
5 105MM RING
6 THERMOSTAT
7 CABLE GRIP
8 POWER CORD
9 TANK ASSEMBLY
10 STEAMBATH INLET CONTROL
11 STEAMBATH LEVEL CONTROL
12 ELEMENT 2000W 230V
13 12 STATION STEAMBATH TRAY
14 PILOT LIGHT
15 SAFETY CAP
16 SAFETY FACIA
Description
MODEL : 12 STATION STEAM BATH
MODEL CODE : 402
