ADJUSTMENTS
12
Swivel Seat Adjustments
Horizontal Adjustment - The seat can be adjusted in
1” increments and is held in place with a spring loaded
adjustment pin. The seat system is easily adjusted by
pulling the seat adjustment rod up and sliding the seat
assembly forward or backward. The seat may also be
adjusted by pressing the foot assist pedal. Adjust the
seat so the arms have a slight bend at full extension.
The feet can be located in the most comfortable area
on the flat surface of the foot rest.
Vertical Adjustment - Pull up on the vertical adjustment
rod to move the seat up or down, to move up take
weight off of seat.
Swivel Adjustment - Push swivel adjustment lever
down and rotate seat, pull lever up and rotate seat
untill it locks into place. The seat will lock into place
at each 90 degree position.
Foot Assist
Pedal
Vertical
Adjustment
Swivel
Adjustment
Horizontal
Adjustment
