Upper Crank Assembly (PRO2/PRO1000 Adjustable)
Tools required:
• 5/32" (4mm) Allen Hex Wrench. (Supplied with machine)
Washer, Flat, .25ID x .835ODScrew, 1/4-20 x 1/2"Left Upper CrankRight Upper Crank
Qty. 4Qty. 4Qty. 1Qty. 1
Attention: Failure to install the washers and screws may cause injury, if crank is facing downward and adjustments are made.
Page 11 of 24
