Assembly
Attaching The R/L Connecting Links
Tools Required:
• 3/16" Allen Hex Bit (5mm)
• Ratchet
Hardware
Screw, 5/16-18 x 1.75" Socket BH Washer, Split 5/16" Washer, Flat 5/16"
Qty. 2 Qty. 2 Qty. 2
Lift left handlebar up and lower the connecting link to align with the telerail, then secure with hardware.
Repeat steps 1 and 2 for the right side.
Page 7 of 20
