Hybex® Microsample Incubator — USER MANUAL
Version 1.9, Oct 2019 11 (408) 733-7337, techserv@scigene.com
V. TROUBLESHOOTING
Symptom Cause Solution
Instrument does not turn on. No power or
blown fuse
Check power source and power cord
connection. Replace fuse beneath
power cord (on back of unit) if
necessary.
Controller is not responding
when buttons are pressed.
Controller is faulty or
the settings have
been corrupted.
Contact SciGene or your distributor to
reset the controller to factory settings
or replace the controller.
VI. SPECIFICATIONS
Electrical
Cat. #1057-30-0 115V AC; 50/60 Hz; 3A
Cat. #1057-30-2 230V AC; 50/60 Hz; 1.6A
Dimensions
Outside (H x W x D) 10 x 6 x 12 inches (21 x 15 x 30 cm) — cover closed
Weight
Instrument 6 lbs (3 kg) — without block
Performance
Temperature Range Ambient +5°C to 99°C
Temperature Regulation ± 0.1°C
Controller
Controller Type Digital PID
Display Four-line LED
Calibration Output T-type Thermocouple
Environmental
Ambient temperature Operation: +15 to +32°C (58 to 90°F)
Storage: -20 to +60°C (-4 to 140°F)
Relative humidity Operation: 15 to 80% RH non-condensing
Storage: 10 to 90% RH non-condensing
VII. ORDERING INFORMATION
Cat. # Description UoM
1057-30-0 Hybex Microsample Incubator, heating base, 115V. EA
1057-30-2 Hybex Microsample Incubator, heating base, 230V. EA
1057-31-0 0.2 ml tube block. Holds 96x0.2ml PCR tubes or single plate EA
1057-33-0 0.6 ml tube block. Holds 60x0.6ml tubes EA
1057-34-0 1.5 ml tube block. Holds 32x1.5ml microcentrifuge tubes EA
1057-39-0 Flat-bottom heat block. Holds a microplate. EA
1057-35-0 Waterbath Insert for Hybex Incubator EA
1057-38-0 Hybex Microarray Chamber Kit. EA
1051-52-0 Digital thermometer. Includes cable and NIST certificate EA
