Scion 2011 xB - Instrument Cluster; Speedometer, Tachometer, and Gauges; Multi-Information Display and Controls; Indicator Symbols and Warnings

4
OVERVIEW
Driver seat belt reminder
1
(alarm will sound if speed is over 12 mph)
Front passenger seat belt reminder
1
(alarm will sound if speed is over 12 mph)
Brake system warning
1
Charging system warning
1
Malfunction/Check Engine indicator
1
Indicator symbols
Instrument cluster
Service indicator and reminder
Speedometer
Tachometer
Fuel gauge
Clock
Outside temperature
Clock button
Odometer and two trip meters
Odometer/trip meter and trip meter reset button
Multi-information display
Multi-information display control switch
Automatic Transmission shift position indicator
1
For details, refer to “If warning light turns on or warning buzzer sounds” Section 5-2,
2011 Owner’s Manual.
For details, refer to “Indicators and warning lights,” Section 2-2, 2011
Owner’s Manual.
