SCM HRLE090 - Pump Capacity

0 10 20 25 30 40
50
Facility water inlet temperature [°C]
Facility water flow rate [L/min]
30
25
20
15
10
5
0
16
0 5 10 15 20 25 30
40
35
Circulating fluid flow rate [L/min]
Circulating fluid pressure [MPa]
0.5
0.4
0.3
0.2
0.1
0
50 Hz
Usable
range
60 Hz
Usable
range
50 Hz
60 Hz
Return port
0 10 20 30 40 50 60
70
Circulating fluid flow rate [L/min]
Circulating fluid pressure [MPa]
0.5
0.4
0.3
0.2
0.1
0
50 Hz
Usable
range
60 Hz
Usable
range
50 Hz
60 Hz
Return port
Mechanical Seal Pump
The pump used for the thermo-chiller HRLE series uses a
mechanical seal with the fixed ring and rotary ring used for the
shaft seal part. If foreign matter enter the gap between the
seals, this may cause a trouble such as leakage from the seal
part or pump lock. Therefore, it is strongly recommended to
install the particle filter in the return piping of the chiller.
Caution
Mechanical seal pump
Mechanical seal
Casing
Mechanical
seal
Shaft
Impeller
HRLE050-m-20
Pump Capacity
Required Facility Water Flow Rate
* This is the facility water flow rate at the circulating fluid rated flow and
the cooling capacity listed in the ”Cooling Capacity” specifications.
* The pump capacity is the capacity of CH1 when 2 L/min are applied
to CH2.
HRLE050-W-20
HRLE090-m-20/40
* The pump capacity is the capacity of CH1 when 2 L/min are applied to CH2.
13-2
HRLE Series
Compact Dual/Basic Type for Lasers
A
