SCM HRLE090 - Page 2

Heater
Circulating fluid
Compressor
Cool fluid
from
refrigerant
Circulating fluid
Compressor
Cool fluid
from
refrigerant
∗ This is just an example diagram.
The hot gas discharged from
the refrigerant is used
instead of a heater.
Existing model
HRLE
Space saving Reduced wiring/labor
The temperatures of 2 fluid channel
systems can be controlled individually.
Compact
One power supply system for temperature
control of 2 channels
Less work-hour for wiring
Power consumption reduced by 17%
¡1 compressor, fan, and pump ¡Uses a heating method that does not require a heater
MVariations
Circulating fluid can be
heated without a heater.
(Circulates the hot discharged gas through
expansion valve B)
Hot discharge gas is recycled for heating.
Energy saving by heaterless heating function
Energy saving
Heaterless
Power cable entry
Cooling
capacity
[kw]
∗
1
Temperature stability [°C] Set temperature range [°C]
Options
p. 19
Accessories (Sold separately)
CH1 CH2 CH1 CH2
Air-cooled
refrigeration
pp. 9, 10
8.0/9.5
±0.1 ±0.5
15 to 25
CH1
temperature
+
0 to 15
· Increased cooling capacity
function (With inverter for
compressor)
· Circulating fluid pressure
adjustment function (With
inverter for pump)
· Deionized water (Pure
water) piping
· G/NPT thread conversion fitting set
· Bypass piping
· Electric conductivity control
(DI filter + Solenoid valve for control)
· Particle filter
· Automatic fluid fill set
· Ball valve set (With pressure gauge)
Water-cooled
refrigeration
pp. 11, 12
9.5/11.0
∗1 CH1, 2 total, 50/60 Hz
Customer system side Customer system side
Chiller q
Chiller w
Series Height Width Depth
HRLE090 1055 445 965
HRSH090 1080 377 970
[mm]
Height
Width
HRLE Existing model
Depth
CompressorCompressor
FanFan
PumpPump
¡Outdoor air temperature: 32°C ¡Circulating fluid set temperature: 20°C/25°C (CH1/CH2) ¡Heat load in the customer equipment: 9.5 kW (CH1, 2 total)
¡Power supply: 200 V 60 Hz ¡Circulating fluid flow rate: 35 LPM/2 LPM (CH1/CH2) to the customer equipment
¡External piping: The shortest distance assumed to the customer equipment
Conditions
1
Circulating Fluid Temperature Controller
Thermo-chiller
Compact Dual/Basic Type for Lasers
Air-cooled Refrigeration Water-cooled Refrigeration
HRLE Series
