Scope Communications UK Ltd
Ref: 40A7PROGMANUAL Page 3 of 11 Issue 1
Programmer Kit
Pager Programmer (YO87) 1 off
Parallel Connection Cable 1 off
9V DC Adaptor 1 off
Program (V3.x) 1 off
Connection
1) Connect the pager programmer to the PC parallel port using the connection
cable provided. Fit the 9V DC Adaptor connection cable to the side of the
Programmer Shoe. Confirm that the red indicator is lit.
2) Copy the programming S/W to your local hard disk.
Programming
1) Start the program and select the relevant features on the two-page menu, as
described below.
2) Remove the battery cover & battery from the pager and insert the pager into
the shoe. Close the locking bar. Click on “Write to Pager” on the top toolbar. The
screen will show progress and will confirm successful completion.
3) To review a pager’s contents, click on “Read from Pager” on the top toolbar.
4) To save a configuration, select File, Save, on the top toolbar. The file can
then be loaded for future use.
To Next Page
