Scosche FD2080 - Vehicle-Specific Radio Removal Procedures (Page 5); Radio Removal: 1999-02 Ford Expedition; 1999-03 Ford F-Series Pickup; 2004 Ford Heritage F-150; 1998-02 Lincoln Navigator; Radio Removal: 2002-05 Ford Explorer 4 Door; 2002-05 Mercury Mountaineer; Radio Removal: 1997-98 Ford Expedition; 1997-98 Ford F-Series Pickup

5
1997-98 FORD EXPEDITION
1997-98 FORD F-SERIES PICKUP
RADIO REMOVAL:
1. Carefully pry out on stereo/dash bezel
and unsnap to remove.
CAUTION: PASSENGER AIRBAG SWITCH
DOES NOT UNPLUG ON PICKUP.
2. Insert DIN removal tools. Spread the tools apart to release
factory stereo, slip it out of the dash and remove stereo.
1999-02 FORD EXPEDITION
1999-03 FORD F-SERIES PICKUP
2004 FORD HERITAGE F-150
1998-02 LINCOLN NAVIGATOR
RADIO REMOVAL:
1. Carefully pry out on stereo/dash bezel and unsnap to remove.
CAUTION: PASSENGER AIRBAG SWITCH
DOES NOT UNPLUG ON PICKUP.
2. Insert DIN removal tools. Spread the tools apart to release
factory stereo, slip it out of the dash and remove stereo.
2002-05 FORD EXPLORER 4 DOOR
2002-05 MERCURY MOUNTAINEER
RADIO REMOVAL:
1. Use panel removal tool to pry out radio trim
bevel and disconnect.
2. Extract (2) two 9/32'' screws, located below
the radio, disconnect and remove.
6604 PANEL
2001-04 FORD MUSTANG
RADIO REMOVAL:
1. Use panel removal tool to pry out gear shift bezel.
2. Use panel removal tool to pry out radio trim bevel.
3. Extract (2) two 9/32'' screws, located below the
radio, disconnect and remove.
6603 PANEL
2004-08 FORD F-150 PICKUP
2005-07 FORD FREESTYLE
2008 FORD TAURUS X
2006-08 LINCOLN MARK LT PICKUP
RADIO REMOVAL:
1. Using panel removal tool, pry loose panel from
around radio, vent, and shifter. Unplug and remove.
2. Remove (4) Phillips head screws from radio brackets. Unplug and remove.
“B” MOUNTING TABS (TOP & BOTTOM)
Pestañas montaje “B”
(Superior e
inferior)
USE “B” MOUNTING TABS (TOP & BOTTOM). CUT OFF THE REMAINING TABS AND DISCARD.
Usar las pestañas “B” (superior e inferior). Cortar las pestañas restantes y descartarlas.
USE 6617/6618 SPACERS WITH SHADED MOUNTING TABS ON 6604
MOUNTING PANEL FOR INSTALLATION. CUT OFF THE REMAINING
TABS AND DISCARD.
Utilice espaciadores 6617/6618 detras de el panel de montaje sombreadas
6604 para instalación. Cortar las pestañas restantes y descartarlas.
6617/6618
SPACERS
6604 PANEL
USE “C” MOUNTING TABS (TOP & BOTTOM). CUT OFF THE REMAINING TABS AND DISCARD.
Usar las pestañas “C” (superior e inferior). Cortar las pestañas restantes y descartarlas.
“C” MOUNTING TABS
Pestañas
montaje “C”
6604 PANEL
USE 6617/6618 SPACERS WITH SHADED MOUNTING TABS ON 6604
MOUNTING PANEL FOR INSTALLATION. CUT OFF THE REMAINING
TABS AND DISCARD.
Utilice espaciadores 6617/6618 detras de el panel de montaje sombreadas
6604 para instalación. Cortar las pestañas restantes y descartarlas.
6617/6618
SPACERS
6604 PANEL
