AC 226 AS 6 Air
AC 226 WS 6 Water
Stainless steel 1 70 Kg.
Start . Electric power cons.
Amps Kwh per 24 Hr
Model Cond. unit Finish Comp. HP
SPECIFICATIONS
Basic electr. Amps Watts Nr. of wires Amps fuse
230/50/1 5.2 29 1180 3 x 1.5 mm
2
16
330*
1800*
AC 226 - CUBER
machine specifications
Cubes per harvest: 72 large / 102 medium / 198 small
* A 15°C water temperature
Dimensions:
HEIGHT (without legs) 1006 mm.
HEIGHT (with legs) 1126 mm.
WIDTH 1078 mm.
DEPTH 715 mm.
WEIGHT 120 Kgs.
24.2
19.2
Bin Water req.
Capacity lt/24 HR
ADJUSTABLE FOOT
OVERFLOW DRAIN
CORD SET
WATER OUTLET - WATER COOLED UNIT
WATER INLET - WATER COOLED UNIT
MIN. FOR UTILITY CONNECTIONS
WATER INLET
