Service - Remove Cabinet
• Drain reservoir
• Disconnect water, power and drain
• Remove door
• Remove back panel
• Remove top panel
• Remove control box cover
• Disconnect thermistor at controller, pull
wire to back of unit
• Remove curtain and hanger
Thermistor
Connection
