Service – Remove Cabinet
• Remove service panel
• Remove kickplate
• Remove air baffle
• Remove 4 bottom corner
screws
• Pull bin thermostat cap
tube from holder – handle
carefully
Air Baffle
Bottom Corner
Screw
