Scotsman MXG Series - Page 97

Time T
a
Added time controlled
by the PC Board
according to the setting
of the DIP SWITCH
1, 2, 3 and 4.
LENGTH OF TIMED PORTION OF FREEZING
CYCLE – FIRST 4 SWITCHES
25’
13’
19’
11’
17’
3’
9’
15’
21’23’
7’ 5’
OPERATING PRINCIPLES – PC BOARD
NEW MXG SERIES
