Time T
s
Harvest Time T
S
is
controlled by the PC
Board and it is inversely
proportional to the Time
T
2
of the Freeze Cycle
(from 0ºC to -13ºC) as
per the combination A
of the Table.
Time T
S
is NOT
adjustable.
LENGTH OF HARVEST CYCLE ACCORDING TO THE TIME
TO DROP THE EVAP. TEMPERATURE FROM 0ºC TO -13ºC
LENGTH PROGRAMS
HARVEST
CYCLE A B C D
180” Up to 6’ *** Up to 9’ ***
165” 6’-7’ Up to 3’ 9’-10’ ***
150” 7’-8’ 3’-3’15’ 10’-11’ ***
135” 8’-9’ 3’15”-3’30” 11’-12’ ***
120” 9’-10’ 3’30”-4’30” 12’-13’ Up to 3’
105” 10’-12’ 430”-6’ 13’-15’ 3-4’
90” >12’ >6’ >15’ >4’
OPERATING PRINCIPLES – PC BOARD
NEW MXG SERIES
