39
Page 32
2. Remove front panel.
3. Wait till the end of the harvest cycle, switch
off the machine, then switch ON again, push
the CLEAN BUTTON on LED display for 2-3
seconds in one minute. The machine should go
to clean/sanitize procedure, and the red
CLEAN LED light on LED display will be fast
blinking in whole procedure.
4. In beginning 30” of clean procedure, machine
will purge water from sump, then pour on
- NW307/308 185 cc
- NW507/508 210 cc
- NW 457/458-608 250 cc
- NW1008 350 cc
- NW1408 350 cc
of Scotsman Ice Machine Cleaner directly into
the reservoir while the water inlet valve will be
energized till the fill up of the water sump. The
water pump starts to operate.
5. After 10 minutes, machine will purge the
clean Cleaner solution, and refill up the water
sump, then go into automatic rinsing mode.
6. At the end of the 10th Rinsing cycle,
according DIP switch #9 setup, the machine:
#9 OFF machine stops the operation and
blinking (slow) of the red Clean
LED.
Push the CLEAN BUTTON when
machine stop, the machine
restarts in the freezing cycle
#9 ON Machine will go to freezing cycle
directly.
7. Replace the evaporator cover deflector and
front panel.
8. Check the next batch of cubes to be sure all
the cleaner is gone (no sour taste).
9. Pour hot water into the storage bin melt the
cubes, and to also clean the bin drain.
RINSING mode consists of:
a) Energize the water pump for 30”.
b) Energize the water drain valve and the
water pump for 30”.
c) Energize the water inlet valve till the fill
upof the water sump.
The above sequence is repeated 10 times
so tobe sure to have removed any possible
trace of Ice Machine Cleaner.
CAUTION:
DO NOT use ice cubes produced
from the cleaning solution. Be sure
none remains in the bin.
