Scotsman SCE170 - Specifications

Specifications
The unit is equipped with an electrical power
cord, but should only be plugged into a circuit
dedicated to the ice machine.
Model
Number
Dimensions
(w/o) legs
H" x W" x D"
Basic
Electrical
Ice Type Condenser
Type
Total
Load
Amps
Total
Wattage
Refrigerant
HP62
(R-404a)
SCE170A-1A
33 x 24
1
⁄
4
x24
115/60/1 “Half-Dice”
Cube
Air 10 see page 18
SCE170A-1C SAME SAME SAME Air 10 see page 18
SCE170W-1A SAME SAME SAME Water 10 see page 18
SCE170W-1C SAME SAME SAME Water 10 see page 18
SCE170A-6C same 230/50/1 SAME Air 5 1150 see page 18
SCE170W-6C same 230/50/1 SAME Water 5 1150 see page 18
Note: A scoop and legs are included. Power Cord Supplied.
Serial
Number
Plate
(Behind Grill)
THE NAMEPLATE IS LOCATED
ON THE BACK PANEL.
A SERIAL NUMBER PLATE IS
LOCATED BEHIND THE RIGHT
FRONT PANEL, ON THE BASE IN
FRONT OF THE CONTROL BOX
SCE170
June 2002
Page 2
