UF424 / UN324 Technical Manual
September 2017
Page 5
61cm
24.0in
72.3cm
28.4in
99cm
39.0in
84.7cm
33.4in
50.8cm
20.0in
AIR
EXHAUST
AIR
INLET
Plan and Front Views
