BIKE OWNERS MANUAL
remount the cap of the cable
housing window on the shock by
turning them clockwise using a
1.5 mm allen key and a maximum
tightening torque of 0.3 Nm
9
Important:
Please note that the maximum pressure of the Equalizer 2 shock is 28.0bars/406psi in
the positive chamber and 22.4bars/325psi in the negative chamber and which means
a maximum weight of the rider of 110kg/243lbs incl. riding gear and load.
recommended tools for the shock set-up
For the set-up of the shock we recommend to use a shock pump with a scale up to 40
bars/600 psi with a special air valve connector preventing from air getting away while
removing the pump from the shock valve, this will result in an exact air pressure.
Please note that air will flow into the hose and indicator when counterchecking the
air pressure, so you have to set up again the recommended pressure after this action.
Make sure to balance at least this air loss when you make a check of the air pressure
of the shock. Pls also note that the indicators of shock pumps have a tolerance of
max. 10%
1
2
3
