26 scott-sports.com 27
GENIUSENGLISH
BIKE OWNERS MANUAL
cable housing length
adjustment of seatpost-height
In order to avoid damages on the frame/derailleur and/or “ghost-shifting” which could
result in dangerous riding please note that under the BB housing the distance between
the cable housing and the BB shell should be minimum 35mm.
Important:
The seatpost has to be inserted into the seattube at a minimum of 100mm.
Never use another seatpost diameter than 34.9mm or try to use a shim/reducer
between seatpost and frame.
35 MM
replaceable dropout
front derailleur fixation
On Genius bikes you can replace the rear derailleur hanger.
In case the replaceable hanger is damaged by a crash or accident you can order at
your local Scott dealer the replacement part with Scott article number 206473
On Genius you will find an E-type front derailleur but fixed directly on the swingarm
without the plate that is fixed normally between the bottom bracket bearing cup and
the bottom bracket housing of the front triangle.
