ENGLISH / PATRON TECH MANUAL
Technical Data:
Seatpost: 31.6 mm
Seatpost Clamp: 34.9 mm
Travel: 160 mm F & R
Shock Length: 205 mm E2E
Shock Stroke: 60 mm
Hardware M/Frame: Trunnion
Hardware Linkage: 17 x 10 mm
Chainring Max: 38 T
Chain Line: 52 mm
Tyre Width Max: 2.6”
Max / Min Rotor:
203 Only
(no special mount)
Tyre sizes often vary from brand
to brand. Always ensure the frame,
linkage & swingarm tyre clearance
is adequate when replacing the
rear tyre.
For the full installation of the motor,
wiring, and frame parts please only take
your bike to an Authorised Scott Dealer
for assistance.
