SCOTT SCALE 970 User Manual

ENGLISH
27 |
ROAD BIKE | OWNER’S MANUAL 2021
e fd
TESTS BEFORE EVERY RIDE
Your SCOTT bike has undergone numerous tests during production and a final
check has been carried out by your SCOTT dealer. Nevertheless, be sure to
check the following points to exclude any malfunctioning that may be due to
the transport of your SCOTT bike or to changes a third person may have per-
formed on your SCOTT bike before delivery:
1. Are the quick-release levers (c), thru axles or nuts of the front and rear wheel,
the seat post (d) and other components properly closed?
For more information see the chapter “Using quick-releases and thru axles”
and the manuals of the component manufacturers.
2. Are the tyres in good condition and do they have sufficient pressure (e)? The
minimum and maximum pressure (in bar or PSI) is indicated on the tyre side.
For more information see the chapter “Wheels and tyres” and the manuals of
the component manufacturers.
3. Spin the wheels to check whether the rims are true. If you have disc brakes,
watch the gap between frame and rim or tyre and, if you have rim brakes,
between brake pad and rim. Untrue rims can be an indication of tyres with
ruptured sides or broken spokes.
For more information see the chapter “Wheels and tyres” and the manuals of
the component manufacturers.
4. Test the brakes in stationary by firmly pulling the brake levers towards the
handlebars (f). The brake pads of rim brakes must hit the rim evenly with
their entire surface without touching the tyre during braking, in open condi-
tion or in between.
You should not be able to pull the lever all the way to the handlebars. If your
bike has hydraulic brakes, check the hydraulic brake cables for oil or brake
fluid leaks! Check the thickness of the brake pads, as well.

SCOTT SCALE 970 Specifications

General

Crankset	Shimano FC-MT511-1, 32T
Saddle	Syncros Belcarra Regular 2.5
Chain	KMC X12
Spokes	Stainless Black 15G / 1.8mm
Frame	Alloy 6061 Custom Butted Tubing
Fork	RockShox Judy Silver TK, 100mm travel
Rear Derailleur	Shimano Deore RD-M6100 12 Speed
Shifters	Shimano Deore SL-M6100-R / Rapidfire Plus
Brakes	Shimano BR-MT200, hydraulic disc
Cassette	Shimano Deore CS-M6100-12 / 10-51 T
Wheelset	Syncros
Tires	Schwalbe Rapid Rob 29x2.25"
Handlebar	Syncros Alloy 6061, T shape Flat, 9° back sweep, 740mm
Seatpost	Syncros / 31.6x400mm
Rotor	Shimano SM-RT30 CL, 180mm(F) / 160mm(R)
H'stem	Syncros Alloy 6061
Headset	Syncros OE Press Fit, Tapered 1.5" - 1 1/8"
Hub (Front)	Shimano MT400
Hub (Rear)	Shimano MT400
Rims	Syncros / 32H
