OWNER’S MANUAL 2021 | ROAD BIKE
| 46
b ca
Position the saddle so that its upper surface is parallel to the ground. Tighten
the bolt gradually and make sure
1) the clamping device is still accurately mounted on the carbon seat post head
and
2) the clamp is tightening evenly around each rail.
Once there is uniform hold on both rails, tighten the bolt gradually with a torque
wrench (a) until you have reached the maximum torque value indicated in New-
ton metres (Nm) on the seat post.
WARNING
Check the bolts by using a torque wrench once a month according to the
values indicated directly on the components and/or in the manuals of the
component manufacturers.
Poorly tightened or loosening bolts can fail. Risk of accident!
COCKPIT ADJUSTMENT
Brake lever reach adjustment on SCOTT road bikes and SCOTT cyclo-
cross bikes
With road bikes the clearance between brake lever/shifter and handlebar can be
adjusted to a minor degree. This gives riders with small hands the convenience
of bringing the brake levers closer to the handlebars.
The first phalanx respectively of the index and the middle finger must reach
around the brake lever (b). Braking from the top with your hands on the upper
end of the brake grips is not an alternative in the long run and in hazardous situ-
ations, you need more manual force and cannot support yourself appropriately.
In the case of Shimano’s Dura-Ace unscrew the chrome cover and tighten the
screw positioned in the front (c). In the case of the Ultegra you need special
insert pieces (d). In the case of both Di2 models you reach the screws from the
rear, after you have removed the hoods.

SCOTT SCALE 970 Specifications

General

Crankset	Shimano FC-MT511-1, 32T
Saddle	Syncros Belcarra Regular 2.5
Chain	KMC X12
Spokes	Stainless Black 15G / 1.8mm
Frame	Alloy 6061 Custom Butted Tubing
Fork	RockShox Judy Silver TK, 100mm travel
Rear Derailleur	Shimano Deore RD-M6100 12 Speed
Shifters	Shimano Deore SL-M6100-R / Rapidfire Plus
Brakes	Shimano BR-MT200, hydraulic disc
Cassette	Shimano Deore CS-M6100-12 / 10-51 T
Wheelset	Syncros
Tires	Schwalbe Rapid Rob 29x2.25"
Handlebar	Syncros Alloy 6061, T shape Flat, 9° back sweep, 740mm
Seatpost	Syncros / 31.6x400mm
Rotor	Shimano SM-RT30 CL, 180mm(F) / 160mm(R)
H'stem	Syncros Alloy 6061
Headset	Syncros OE Press Fit, Tapered 1.5" - 1 1/8"
Hub (Front)	Shimano MT400
Hub (Rear)	Shimano MT400
Rims	Syncros / 32H
