SCOTT SCALE 970 User Manual

ENGLISH
| 54
OWNER’S MANUAL 2021 | ROAD BIKE
With an unapplied brake the brake pads should not be too close to the rim
sides, otherwise they could drag along the rim during riding. Before making this
adjustment, observe the notes in the chapter “Brake lever reach adjustment on
SCOTT road bikes and SCOTT cyclo-cross bikes”.
With ongoing brake pad wear, the pressure point at the brake lever moves to-
wards the handlebars. Check the free travel at regular intervals; it should not be
longer than a quarter of the whole travel. For readjustment turn the knurled nut
or bolt (d) through which the cable runs into the brake body until the lever has
the desired travel. Test the brakes subsequently in a place free of traffic.
WARNING
Always test the brakes’ function when stationary after adjusting them, mak-
ing sure the brake pads engage fully with the rim without touching the tyre
when you pull them hard. Make sure you cannot pull the lever all the way to
the handlebars.

SCOTT SCALE 970 Specifications

General

Crankset	Shimano FC-MT511-1, 32T
Saddle	Syncros Belcarra Regular 2.5
Chain	KMC X12
Spokes	Stainless Black 15G / 1.8mm
Frame	Alloy 6061 Custom Butted Tubing
Fork	RockShox Judy Silver TK, 100mm travel
Rear Derailleur	Shimano Deore RD-M6100 12 Speed
Shifters	Shimano Deore SL-M6100-R / Rapidfire Plus
Brakes	Shimano BR-MT200, hydraulic disc
Cassette	Shimano Deore CS-M6100-12 / 10-51 T
Wheelset	Syncros
Tires	Schwalbe Rapid Rob 29x2.25"
Handlebar	Syncros Alloy 6061, T shape Flat, 9° back sweep, 740mm
Seatpost	Syncros / 31.6x400mm
Rotor	Shimano SM-RT30 CL, 180mm(F) / 160mm(R)
H'stem	Syncros Alloy 6061
Headset	Syncros OE Press Fit, Tapered 1.5" - 1 1/8"
Hub (Front)	Shimano MT400
Hub (Rear)	Shimano MT400
Rims	Syncros / 32H
