SCOTT SCALE RC User Manual

2023 SCALE | ENGLISH 4
|
SCALE
SCALE
GEOMETRY & TECHNICAL DATA CONT.
The rear brake calliper is a post mounted 160mm
without an adapter.
The maximum rotor size is 180mm, except on
a small size frame where it must not exceed
160mm.
If you wish to use two piston brake callipers, you
must check the clearance, as not all two piston
brakes will fit.
Please note that on a small size frame it is
only possible to use a 500 ml water bottle,
with a side entry cage.
Carbon frames will have a unique insert for
the rear axle.

SCOTT SCALE RC Specifications

General

Fork	RockShox SID SL Select
Rear Derailleur	SRAM GX Eagle
Crankset	SRAM X1 Eagle, 32T
Tires	SCHWALBE RACING RAY 29X2.25" EVO / SUPER RACE / TLE / 67EPI / SCHWALBE RACING RALPH 29X2.25" EVO / SUPER RACE / TLE / 67EPI
Shifters	SRAM GX Eagle
BB-Set	SRAM DUB
Chain	SRAM GX Eagle
Cassette	SRAM XG-1275, 10-52T
Seat	Syncros Belcarra Regular
