OPERATION
LED FUNCTION OF CHARGER
Battery Pack / Charger Green LED Red LED Action
Stand by Off On Power on.
Charging Flashing On Battery is being charged.
Battery fully charged /
Energy save mode
On On
Charging is complete; charger maintains charge mode / turns
to Energy Save mode.
Hot battery pack
When battery pack reaches cooled temperature, charger be-
gins charge mode.
Cold battery pack Flashing Flashing
When battery pack reaches warmed temperature, charger
begins charge mode.
Deeply discharged
Charger conditions battery until normal voltage is reached,
then begins charge mode.
Defective battery Off Flashing
• If defective, try to repeat the conditions a second time by
removing and reinstalling the battery pack. If the LED
status repeats a second time try charging a different
Scotts 62 Volt battery.
• If a different battery charges normally, properly dispose
of the defective battery pack.
• If a different battery also indicates “defective”, the charger
may be defective.
Defective charger Off Off No light indicates the charger may be defective
LED FUNCTION OF BATTERY PACK:
• During charging, the four (4) LED lights will flash green one by one in a circular manner.
• When the battery capacity reaches 25%, one (1) LED light will be constant while the remaining three
(3) will continue to flash.
• When 50% capacity is reached, two (2) LED lights will be constant while the remaining two (2) will
continue to flash.
• When 75% capacity is reached, three (3) LED lights will be constant while the last light will continue
to flash.
• When the battery is fully charged, all four (4) LED lights will remain constant.
• After 30-60 minutes, including charging time, the lights will automatically shut off.
• During use, pressing the button will turn on the lights showing how much charge is left on the battery.
The lights will automatically shut off after 3 to 5 seconds.
• When battery pack reaches 70ºC , the built in thermal protection will stop the unit to protect the
battery from damage. Remove the battery pack from the unit and allow it to cool to below
50ºC . Once the battery has cooled, you may reinsert the battery and resume the job.
• During charging, if battery temperature reaches 50ºC , the thermal protection will be activated
and charging will be halted. When battery cools to less than 45ºC, charging will resume. It is
advisable to remove the battery from the charger and allow ample time for cooling so the battery can
be fully charged without interruption.
• If battery temperature is below 0ºC , battery cannot be charged. Charging will begin when battery
warms to over 5ºC .
5
Model CHL86200
