PRODUCT SPECIFICATIONS
Model: TC70105S
Power supply voltage: 120V-60HZ Working width: 7-IN or 11-IN
Tine Speed: 350 RPM Working depth max: 8-IN
Power Consumption: 10.5 Amp
No. Description No. Description
1 Upper handle section 11 Wheel hub cap
2 Bail wire 12 Wheel frame lock pin
3 Switch box and power cable assembly 13 Motor housing
4 Cable clip 14 Protective shield
5 Cord retainer 15 Tine assembly, D
6 Wing nut 16 Tine assembly, C
7 J-bolt M6 17 Tine assembly, B
8 Center handle section 18 Tine assembly, A
9 Lower handle section - II 19 Tine lock pin
10 Lower handle section - I 20 Wheel
4
Model TC70105S
1
