SCREEN SERVICE SDT200UB - Table 49. ST Parameters; Table 50. TDT Parameters

ISO 9001:2000 Cert. N°4500/1
Version 1_2 SDT_ARK6_User_Manual_ENG_v1_2.doc Page 190 of 468
Table
Parameter / Control
Description
Admitted Ranges / Values
SIT
Running Status
This 3-bit field indicates the running status of the event in the
original stream. This is the running status of the original present
event. If no present event exists in the original stream, the status is
considered as “not running” inactive. The meaning of the
running_state value is as defined in ARIB STD-B10.
0-7
Table 49. ST parameters
Table
Parameter / Control
Description
Admitted Ranges / Values
ST
ST PID
PID of the ST table.
0 – 8191, except 0x0000, 0x0001,
0x0014 and the PIDs reserved according
to the standard.
ST
Table Id
Table ID of the ST table. This field is indicator only, and it must be
set always to 114 according to ABNT NBR 15603-2 standard.
114
ST
Section Syntax
Indicator
This 1-bit field may take either the value "1" or "0".
0-1
ST
Data Byte
This 8-bit field may take any value and has no meaning.
Any value.
Table 50. TDT parameters
Table
Parameter / Control
Description
Admitted Ranges / Values
TDT
TDT PID
PID of the TDT table. This field is indicator only, and it must be set
always to 20 according to ABNT NBR 15603-2 standard.
20
TDT
Table Id
Table ID of the TDT table. This field is indicator only, and it must be
set always to 112 according to ABNT NBR 15603-2 standard.
112
